Ecosystem

This analysis is built on the modern Scikit-HEP ecosystem, a coordinated collection of libraries designed for providing Particle Physics at large with an ecosystem for data analysis in Python. Some of the tutorials for Scikit-HEP can be found here and some more from HSF here.

1. From Event Loops to Array-Based Processing

Traditional High-Energy Physics analysis has historically relied on an event-loop paradigm: iterating through the dataset one event at a time, reconstructing objects, and filling histograms sequentially. While conceptually simple, this approach suffers from poor performance in Python due to interpreter overhead and the absence of vectorization.

This analysis instead uses columnar processing:

Rather than looping over every muon in every event to check its Transverse momentum, we operate on the entire Transverse momentum array at once—a single NumPy-like operation. The computational burden shifts to compiled, highly optimized C++ kernels.

This approach enables CPU vectorization, reduces Python overhead, and, when combined with Dask for parallelism, allows the same code to scale from a laptop to a full computing cluster without modification. You can read more about "array-oriented" programming or "coloumnar" processing here.

2. The Scikit-HEP Stack

Each library in the stack addresses a specific challenge of HEP data processing:

2.1 Uproot: ROOT I/O without ROOT

Uproot reads and writes ROOT files using pure Python, with no dependency on the C++ ROOT framework. In this analysis, Uproot handles the input/output layer, streaming NanoAOD TTrees from remote XRootD servers directly into memory as NumPy and Awkward arrays.

2.2 Awkward Array: Jagged data structures

Particle physics data is inherently irregular: one event may contain zero muons, while the next may have three. Standard flat libraries like NumPy cannot represent this naturally.

Awkward Array provides jagged array operations that allow us to manipulate these irregular, nested structures using NumPy-like idioms (slicing, masking, and broadcasting) without losing the event structure.

2.3 Vector: Lorentz four-vector arithmetic

Calculating physical quantities such as invariant masses (\(m_{\ell\ell}\)), angular separations (\(\Delta R\)), and Lorentz boosts is handled by the Vector library. It integrates seamlessly with Awkward Array, allowing us to perform complex 4-vector arithmetic on millions of particles simultaneously:

# Reconstruct the dilepton system from individual lepton four-vectors
dilepton = lepton1 + lepton2
m_ll     = dilepton.mass

2.4 Hist: Multi-dimensional histograms

For the final accumulation of yields and distributions, we employ Hist. Based on the fast C++ boost-histogram library, Hist supports multi-dimensional, sparse, and categorical axes. This is essential for our analysis, which requires simultaneous categorization of events into multiple regions (Signal, Control) and systematic variations within a single object.

2.5 mplhep: CMS-style plotting

mplhep is a Matplotlib extension for high-energy physics. It provides tools for plotting data in the standard HEP style, including axis formatting, error bar conventions, and legend placement. In this analysis, mplhep is used to create standardized plots of the signal and control regions.

3. Distributed Computing with Dask

To handle the massive scale of CMS data (terabytes of information), we leverage Dask, a flexible parallel computing library. Dask allows us to scale the same Python analysis from a single laptop to a cluster of machines without rewriting the code. It achieves this by breaking the dataset into smaller “chunks” (partitions) and processing them in parallel.

In this analysis, Dask is used to distribute the event processing across multiple CPU cores, significantly reducing the runtime.

To quantify the performance gain, we compare the wall-clock time required to process the full dataset:

  • Sequential Processing: Processing the full dataset on a single core would be CPU-bound, taking several hours to complete.
  • Distributed Processing: By distributing the workload across the Dask cluster, the total processing time is reduced to minutes.
Mode Setup Approximate runtime
Sequential Single Python process Several hours
Distributed multi-core LocalCluster ~8–12 minutes

This reduction in runtime is important for the iterative nature of the analysis, where selection cuts and strategies are refined repeatedly. Faster processing enables quicker feedback and more efficient development cycles.

4. Full Dependency Table

Core

  • python — Language runtime
  • numpy — Numerical arrays
  • scipy — Statistical utilities

I/O and Data Structures

  • uproot — ROOT file I/O
  • awkward — Jagged array operations
  • fsspec-xrootd — XRootD file access

Physics and Analysis

  • vector — Lorentz four-vector arithmetic
  • hist — Histogramming

Parallel Computing

  • dask — Distributed/parallel computing

Visualization

  • matplotlib — Plotting base
  • mplhep — CMS-style plots

Environment

  • jupyterlab — Notebook environment

Full pinned versions: see requirements.txt and environment.yml.
